Paper and cardboard balers

Paper and cardboard balers Paper and cardboard balers Paper and cardboard balers Paper and cardboard balers
Paper and cardboard balers миниатюра
Paper and cardboard balers миниатюра
Paper and cardboard balers миниатюра
Paper and cardboard balers миниатюра

Do you like our product?

Enquiry

A powerful and reliable paper and cardboard pressing machine, ideal for recycling and reducing waste in industrial environments. A powerful and reliable paper and cardboard pressing machine, ideal for recycling and reducing waste in industrial environments.

  • Warranty, m.: 12
  • Automatic chain bale ejector for quickly and easily ejecting the bales out from the machine
  • Wide feed opening door lifts upwards automatically when the platen goes up
  • The ram will stop running downwards when the feeding gate is opened which ensure the safety of the operation
  • Equipped with independent emergency stop for safe operation
  • Equipped with Euro and U.S standard anti-rebound gate structure which makes sure the safety of operation
  • Special ram guides design makes the platen not slope because of uneven materials feedings during compression
  • Equipped with NOK seals that from Japan means longer lifespan of the seals
  • Equipped with A.M.C. oil pipe joints that from Japan ensures the machine far away from oil leakage problems
  • Equipped with superimposed valves that from Taiwan,, less space required for the installation
  • Peculiar combination of motor and pump with direct-crossed connection makes sure 100 percent concentricity, which
    replacing the common coupling connection so that extend the lifespan of the pump
  • Cross-cylinder desing reduces the height of the balers, conveniently for transportation, installation and maintenance
  • PLC control system ensures the uniform bale weight
  • Low noise design. ensures the noise no more than 70db
Model300LJ12080500LJ12080300LE11070400LE12080500LE15076600LE180100
Pressure30tons50tons30tons40tons50tons60tons
Feed Opening Size (L*H)1050*550mm1050*550mm1100*500mm1200*500mm1500*500mm1800*500mm
Baling Chamber Height1600mm1600mm1400mm1500mm1500mm1600mm
Bale Size (L*W*H is adjustable)1200*800*(500-1000)mm1200*800*(500-1000)mm1100*700*(500-900)mm1200*800*(600-1000)mm1500*760*(600-1000)mm1800*1000*(700-1050)mm
Bale Weight200-400kgs300-500kgs150-250kgs200-450kgs300-500kgs500-700kgs
Power4kw4/5.5kw5.5kw7.5kw7.5kw11kw
Machine Weight2200kgs2800kgs1900kgs2300kgs2800kgs4500kgs
Machine Overall Dimension1800*1400*2225mm1800*1400*2225mm1500*1050*2900mm1600*1200*3100mm2000*1150*3100mm2260*1350*3170mm
